Bettis BHH Series Helical Spline Hydraulic Valve Actuator
Hydraulic helical valve actuator can be operated in the most severe conditions while providing a compact valve automation solution.
- Power Source
- Hydraulic
- Product Type
- Hydraulic Actuator
- Actuation
- Quarter-turn, double-acting, spring-return, helical spline
- Certifications
- ATEX
- Control Type
- On/Off, ESD
- Valve Type
- Ball, butterfly, plug, triple offset, quarter-turn valves, dampers or louvers
- Operating Temperature
- Standard -20°C to +80°C (-5°F to +180°F). Consult factory for low-high temperatures.
- Torque/Thrust
- 1,000 to 142,000 in-lbs at 2,000 psi
- Operating Pressure
- 40 to 207 bar, 580 to 3,000 psi
