Fisher™ Types N551 Snappy Joe緊急關斷閥-費希爾Fisher
點擊圖片查看原圖
品牌： 費希爾FISHER
單價： 面議
所在地： 上海
有效期至： 長期有效
最后更新： 2020-11-24 09:02
瀏覽次數： 410
詢價
店鋪基本資料信息

 產品詳細說明
Fisher™ Types N551 Snappy Joe緊急關斷閥-費希爾Fisher

Type N551 Snappy Joe Emergency Shutoff Valves are intended for in-line use on LP-Gas or Anhydrous Ammonia (NH3) service. The valves may be installed on both ends of transfer hoses where the hose connects the bulk plant piping to the bobtail, transport, or tank car. They provide a quick way of automatically shutting off gas flow in the event of a hose rupture. A fusible element in the latch melts if the temperature reaches 212°F / 100°C, allowing the valve to self-close.

Features

  • Operational Ease
  • Cable Release
  • Rugged Construction
  • High-Flow Capacity
  • Fusible Element
  • Soft Seat
  • Ease of Service
  • Pneumatic Operation
  •

Specifications


Body Sizes and End Connection Style
1-1/4, 2, and 3-inch FNPT
Maximum Inlet Pressure
400 psig / 27.6 bar WOG
Temperature Capabilities
-20 to 160°F / -29 to 71°C
